Cranks e*spec Plus Crank | 165mm | Brose S Mag (CS3LPA-102) (CTN10)

$148.95 Inc. GST
In Stock

Chainring Interface
Model
Crank Length
Colour
Level

e*thirteen eBike Crank Arms

HELIX RACE E*SPEC ALLOY CRANK

HIGH PERFORMANCE. CONFIDENCE ON ANY TERRAIN.
Helix Race e*spec Alloy Cranks offer a high performance alternative to carbon fiber for riders that prefer alloy or don’t want to pay for carbon to get a premium product. Forged and extensively CNC finished, the Helix Race e*spec Crank is a piece of machining art to personalize your fit and dream e-bike build.

These cranks are a serious upgrade that will increase strength and pedal strike resistance while reducing your bike’s weight. Available in eMTB rider-preferred lengths for improved pedal clearance on low BB frame geos. Equipped with built-in alloy self extracting crank bolts for ease of installation and removal when it’s time to service.

Compatible with Bosch, Brose S Mag, TQ, Fazua*, Yamaha, Maxon and Specialized® Brose motor systems using the 24mm ISIS standard. They feature narrow offsets for traditional MTB Q Factor feel while offering enough clearance for motors and
chainstays.

Don’t let the light weight fool you. The Helix Race e*spec Alloy Cranks are tested to exceed E-Enduro EN17406 Class 4 standards and come equipped with custom crank boots for heavy hitting, impact resistant confidence on any terrain.

PRODUCT SPEC
Chainring - Helix Race E*spec Chainring (sold separately)
Colour(s) - Black, Bronze
Compatibility - Compatible with Bosch, Brose S Mag, TQ, Fazua*, Yamaha, Maxon and Specialized® Brose motor systems

(Not compatible with Fazua Ride 60)

Included - Crankset, Crank Boots (x2), Sticker, User Manual
Length - 155mm, 160mm, 165mm
Material - Forged, CNC Machined AL-6066-T6 arms
Spindle - Compatible with 24mm ISIS Spindles
Weight(s)
155mm: 413g
160mm: 431g
165mm: 433g



HELIX CORE E*SPEC ALLOY CRANK

E-mtb Crank Upgrade. Performance Value.
Helix Core e*spec cranks give your e-bike an upgrade with high-end integrity and aesthetics at a great value. Engineered for e-MTB strength, so you don’t need to worry about pedal strikes or holding back on your next gravity run. Forged aluminum arms keep you confident on the trail, while alloy self-extracting crank bolts mean efficient routine service, and minimum added weight. Added details like pedal washers, molded impact boots, and e-rider preferred shorter lengths deliver all the high-end features you'd expect from a crankset well over its price.

PRODUCT SPEC
Chainring - Helix Race E*spec Chainring, Helix Core Steel Chainring, e*spec Plus rings, 104BCD spider, or other rings designed to fit Bosch G4, Brose S Mag, or TQ HPR50 (sold separately)
Color - Black
Compatibility - Compatible with Bosch, Brose S Mag, TQ HPR 50, and Fazua Ride 60
Included - Crankset, Crank Boots (x2), Sticker, User Manual
Length - 155mm, 160mm, 165mm, 170mm
Material - Forged AL-6066-T6 arms
Spindle - Compatible with 24mm and 30mm ISIS Spindles
Weight -
24mm | Bosch | Brose | TQ Model Weights
155mm: 481g
160mm: 497g
165mm: 513g
170mm: 529g

30mm | Fazua Model Weights
155mm: 448g
160mm: 463g
165mm: 478g
170mm: 493g



e*Spec Plus eBike cranks (alloy)
We're now bringing our World Cup proven technology to the eBike marketplace, with our e*spec Plus Alloy Cranks.

Available for Bosch Gen4 CX, Brose S Mag drive, TQ, Fazua Ride 50 and Shimano EP8 & E7000/E8000 systems.
(Shimano E7000/E8000 require conversion kit CSS30-114)

PRODUCT SPEC
Chainring - e*spec Direct Mount Chainring available.
Color - Stealth Black
Compatibility - Select Shimano EP8™️ (E8000 with ETS-CKCSS30-114 adaptor) and Bosch™️ CX Gen4 motor systems - Brose™️ S Mag also compatible with Fazua and TQ motors.
Features - Slim Q factor, low overall profile and volume.
Included - Crankset, Sticker, User Manual
Length - 160mm, 165mm, 170mm, 175mm (not all models)
Material - 6061 Aluminum
Mount - Bosch™️ CX Gen4 or Brose™️ S Mag or Shimano™️ EP8
Self Extractor - No
Spindle INTERFACE: Bosch™️ CX Gen4 or Brose™️ S Mag or Shimano™️ EP8
Weight
Bosch CX Gen 4
160mm: 502g - 165mm: 510g - 170mm: 520g
Shimano EP8 (also fits E8000 with ETS-CKCSS30-114 adaptor)
160mm: 470g - 165mm: 480g - 170mm: 494g - 175mm: 500g
Brose S Mag
160mm: 468g - 165mm: 478g - 170mm: 488g


e*Spec Race Carbon eBike cranks
We're now bringing our World Cup proven technology to the eBike marketplace, with our e*spec Race Carbon Cranks.

PRODUCT SPEC

Chainring - e*spec Direct Mount Chainring available.
Colour - Stealth Black w/Protective Vinyl
Compatibility - Bosch CX Gen4 / Brose S Mag also compatible with Fazua and TQ Motors
(NOT compatible with Fazua Ride 60 with ETOR spindle)

Features - World Cup proven layup. Slim Q factor, overall profile, and volume. 8mm self-extractor in each arm.
Included - Crankset, APS Adjuster, Installation Tools, Crank Boots (x2), Sticker, User Manual
Length(s) - 160mm, 165mm, 170mm
Material - World-Cup DH-rated layup and construction, compacted carbon fiber, with additional 3k added to front and rear faces of crank for impact resistance
Self Extractor - Yes
Spindle - INTERFACE: Bosch CX Gen4 or Brose S Mag
Weight(s)
Bosch Gen 4 - 160mm: 364g - 165mm: 358g - 170mm: 368g

Brose S Mag Fazuza - 160mm: 343g - 165mm: 324g - 170mm: 328g

Shimano EP8 - 165mm: 400g

(ETG-CA-PAR)

SKU ETG-CA-PAR
Brand e*thirteen
Shipping Weight 0.8000kg
Shipping Width 0.280m
Shipping Height 0.070m
Shipping Length 0.250m
Shipping Cubic 0.004900000m3
